IQBOARD QA1300 Pro 65” QA1300Pro65
Business Solutions
Meeting Room & Boardroom
IQ interactive displays QA1300Pro65 are equipped with collaboration tools that allow team members to work together more efficiently. With the integration of cutting-edge audio and video technology, participants can communicate with each other seamlessly.
Features
- The advanced Android 13 with IQ OS
- 4K AI Camera and 8-Microphone Array
- Precision Touch and Writing Enhancement
- Q Button Customization
- DMS Remote Control
- NFC Access Control
- Touch-Free Control and Health Monitoring
Education Solutions
Simple, flexible, connected solutions
We help teachers and students leverage devices and platforms to enhance learning and improve outcomes. IQ education solutions enable more interactive learning experiences and more meaningful feedback. Whilst having one of the most user-friendly offerings in the education market. Our Q-NEX brand also provides solutions to realize IoT control of classroom devices and AV broadcast throughout a campus!
We help teachers and students leverage devices and platforms to enhance learning and improve outcomes. IQ education solutions enable more interactive learning experiences and more meaningful feedback. Whilst having one of the most user-friendly offerings in the education market. Our Q-NEX brand also provides solutions to realize IoT control of classroom devices and AV broadcast throughout a campus!
Features
- The advanced Android 13 with IQ OS
- 4K AI Camera and 8-Microphone Array
- Precision Touch and Writing Enhancement
- Q Button Customization
- DMS Remote Control
- NFC Access Control
- Touch-Free Control and Health Monitoring
Specifications
Display
- Model: LE065MD
- Diagonal Size: 65″
- Brightness: 350 cd/m2
- Contrast Ratio: 1200:1
- Panel Type: TFT
- Backlight: Direct LED (DLED)
- Resolution: 4K UHD (3840×2160)
- Display Ratio: 16:9
- Response Rate: 8 ms (typ.)
- Refreshing Frequency: 60 Hz
- Viewing Angle: 178°(H), 178°(V)
- Backlight Life Time: 50,000 hrs
- Display Colors: 10bit(D), 1.07 Billion colors
- Glass: 4 mm Tempered Glass with Anti-Glare coating (8H)
- Dynamic Contrast Ratio: 5000:1
Interactivity
- Touch Technology: Infrared
- Touch Point: 40-point touch; 40-point writing under Windows; 20-point writing under Android
- Touch Resolution: 32768 × 32768 px
- Response Rate: <4 ms (single touch); <6 ms (max touch inputs)
- Touch Accuracy: ≤1 mm
- Recognition: Finger or pen
- Writing Height: 3 mm
- Minimum Touch Object: 2 mm
- Supported O.S.: HID Support & Win10/Win8/Win7/Mac OS/Android/Chrome OS/Linux
Physical Specifications
- Net Weight: 40 Kg±1.5 Kg
- Gross Weight: 46 Kg±1.5 Kg
- Product Size (mm) (W × H × D): 1501 × 930 × 87
- Packing Size (mm) (W × H × D): 1576 × 980 × 200
- VESA Hole: 4-M8 screw
- Position hole (mm): 500 × 400
Environmental
- Working Temperature: 0°C ~ 40°C
- Storage Temperature: -20°C ~ 60°C
- Working Humidity: 20% ~ 80% RH Non-Condensing
- Storage Humidity: 20% ~ 90% RH Non-Condensing
Power
- Voltage: 100V~240V AC 50 / 60Hz
- Maximum Power: ≤350W
- Standby Power: ≤0.5W
Front Buttons
- POWER, HOME, BACK, SETTING, CUSTOM
IQTouch QA1300 Pro Specifications
- Air sensors: Temperature, Humidity, VOC, PM2.5
- Language OSD: English, French, German, Russian, Japanese, Korean, Polish, Portuguese, Vietnamese, Spanish, Italian, Arabic, Simplified Chinese, Traditional Chinese
Android
- CPU Framework: Cortex-A73*4 + Cortex-A53*4
- CPU Processor Speed: 2.2GHz
- GPU: Arm Mali-G52 MP8 (8EE)
- RAM: 8G
- ROM: 128G
- OS Version: 13.0
- Hotspot: IEEE 802.11 a/b/g/n/ac, IEEE 802.1x, WPA2, station mode (2.4G/5G Dual-band)
- Bluetooth: 5.2
- NFC: YES
- WiFi: IEEE 802.11 a/b/g/n/ac/ax, IEEE 802.1x, WPA2, Wi-Fi6, station mode (2.4G/5G Dual-band)
OPS (Optional)
- Chipset: Intel
- CPU: Intel® Core i3/i5/i7
- Memory: 4GB/8GB/16GB
- HDD: 500GB/1TB
- SSD (optional): 128GB/256GB/512GB
OPS Interfaces (Subject to model)
- USB2.0: 2
- USB3.0: 2
- LAN: 1
- HDMI: 1
- LINE-OUT: 1
- MIC-IN: 1
Connectivity
- Front USB (Android&PC) 3.0: 3
- HDMI IN 2.0: 1
- Touch-USB: 1
- TYPE-C (USB2.0&Video&Audio&Touch&65W): 1
- RJ45 (10/100/1000 Mbit/s): 1
- HDMI 2.0 (4K@60fps): 2
- TYPE-C (USB2.0&Video&Audio&Touch&65W): 1
- USB2.0 (Android) Type-A: 2
- USB3.0 (Android&PC) Type-A: 2
- USB2.0 (for Touch) Type B: 2
- USB2.0 (OTG): 1
- TF Card: 1
- MIC IN: 1
- RS232: 1
- DP: 1
Output
- HDMI 2.0 (4K@60fps): 1
- COAX SPDIF OUT: 1
- EARPHONE (3.5 mm Line Out): 1
- RJ45 (10/100/1000 Mbit/s): 1
Built-in Camera
- 48M (Built-in 4K AI Camera with Auto Framing & Voice Tracking)
Array Microphone
- YES (8 Array microphone)
Built-in Speaker
- 20W*2 + 20W
Light Sensitivity
- YES
Temperature Monitor
- YES
Proximity Sensor
- YES
